Hikvision 4 Wire HD Video Intercom Kit

Door station/Video parameters

• Supplement light IR light, up to 3 m
• Resolution Stream resolution: 1280 * 720@60fps
• FOV Horizontal: 117°, Vertical: 70°, Diagonal: 141°

Door station/Audio parameters

• Audio input Built-in omnidirectional microphone (≤50 cm)
• Audio output Built-in loudspeaker (30 cm/76 dB, 50 cm/72 dB)

Door station/Device interfaces

• Lock control 1 relay, max 30V 1 A
• Debugging port 1
• Four-wire 1 four-wire interface

Door station/General

• Button 1 physical button(s)
• Power supply 12 VDC
• Power consumption Max. 4W
• Working temperature -30° C to + 60° C
• Working humidity 10% to 90%
• Dimensions 145 mm × 55 mm × 24 mm (5.71″ × 2.17″ × 0.94″)
• Application environment Outdoor
• Installation Surface mounting/
• Material Metal
